LH13QBREBGCXUE – QBR 13″ Full HD Small Display – SAMSUNG

Description

QBR 13″ Full HD Small Display

• Enhanced communication in a compact display
• Crisp and visible content
• Slim, smart design

 Display

• Diagonal Size 13″
• Panel Type ADS
• Resolution 1,920 x 1,080
• Pixel Pitch (HxV, mm) 0.153 (H) x 0.153 (V)
• Brightness (Typical, cd/m2) 300
• Contrast Ratio 800:1
• Viewing Angle (H/V) 178/178
• Response Time 8ms
• Color Gamut 45 %
• Glass Haze 25 %
• H-Scanning Frequency 30~81kHz
• Maximum Pixel Frequency 594MHz
• V-Scanning Frequency 48~75Hz
• Contrast Ratio (Dynamic) 10000:1

Connectivity

• HDMI In 1
• DP In No
• USB 1
• IR In No
• HDBaseT In No
• Audio In No
• Audio Out Stereo Mini Jack
• Video Out No
• RS232 In Yes
• RS232 Out No
• RJ45 In Yes
• RJ45 Out No
• WiFi Yes
• 3G Dongle No

Power

• Power Supply AC100-240V 50/60Hz
• Power Consumption (On Mode, W) 27.5
• Power Consumption (Sleep Mode, W) 0.5

Dimension

• Set Dimension (WxHxD, mm) 322 x 193.5 x 28.2
• Package Dimension (WxHxD, mm) 376 x 132 x 248

Weight

• Set Weight (kg) 0.9
• Package Weight 1.7 kg

Operation Conditions

• Temperature 0℃~ 40 ℃
• Humidity 10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount (mm) 100 x 100
• Bezel Width (mm) 12.2
• Frame Material Non-Glossy

General Feature

• External Memory Slot No

Optional Feature

• Mount No
• Stand Inbox(Simple Stand) (2ea)

Internal Player (MagicInfo)

• MagicInfo Daisychain Videowall Support No

Eco

• Energy Efficiency Class B

Certification and Compliance

• EMC Class B
• Safety 60950-1
